74404084470

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-LQS Nonstandard 0.315Lx0.315W 8.00mmx8.00mm 47muH
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.008172
≥1 USD $1.008172
≥10 USD $0.951102
≥100 USD $0.897272
≥500 USD $0.846476
≥1000 USD $0.798574
Inventory: 921
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 8mm
Length 8.001mm
Height Seated (Max) 0.165 4.20mm
Height 4.2mm

Technical

RMS Current (Irms) 1.55A
Inductance Tolerance 20%
Current - Saturation 1.9A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 9.8MHz
Max DC Current 1.55A
DC Resistance (DCR) 136mOhm
Test Frequency 100kHz
Inductance 47μH
Current Rating 1.55A
Shielding Shielded
Current Rating (Amps) 1.55A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Series WE-LQS
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Supplier Device Package 8040
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 13 Weeks
