74404084150
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LQS Nonstandard 0.315Lx0.315W 8.00mmx8.00mm 15muH
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.066132
≥1 USD $1.066132
≥10 USD $1.005789
≥100 USD $0.948855
≥500 USD $0.895141
≥1000 USD $0.84448
Inventory: 8894
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 8040
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-LQS
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 2.6A
Shielding Shielded
Current Rating 2.6A
Inductance 15μH
Test Frequency 100kHz
DC Resistance (DCR) 47mOhm
Max DC Current 2.6A
Frequency - Self Resonant 17MHz
Inductance Frequency - Test 100kHz
Current - Saturation 3.2A
Inductance Tolerance 20%
RMS Current (Irms) 2.6A
Dimensions
Height 4.2mm
Height Seated (Max) 0.165 4.20mm
Length 8.001mm
Width 8.001mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
