74404042068
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LQS Nonstandard 0.157Lx0.157W 4.00mmx4.00mm 6.8muH
PDF
/
Buying Options
Total Price: USD $8.11
Unit Price: USD $8.1149
≥1 USD $8.1149
≥10 USD $6.65855
≥100 USD $6.4505
≥500 USD $6.24245
≥1000 USD $6.0344
Inventory: 1117
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 4018
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-LQS
Size / Dimension 0.157Lx0.157W 4.00mmx4.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 1.45A
Shielding Shielded
Current Rating 1.45A
Inductance 6.8μH
Test Frequency 100kHz
DC Resistance (DCR) 98mOhm
Max DC Current 1.45A
Frequency - Self Resonant 39MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.8A
Inductance Tolerance 20%
RMS Current (Irms) 1.45A
Dimensions
Height 1.8mm
Height Seated (Max) 0.071 1.80mm
Length 3.9878mm
Width 3.9878mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
