744031680
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TPC Nonstandard 0.150Lx0.150W 3.80mmx3.80mm 68muH
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.105661
≥1 USD $1.105661
≥10 USD $1.043075
≥100 USD $0.98403
≥500 USD $0.928335
≥1000 USD $0.875785
Inventory: 5773
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 3.8mm
Length 3.8mm
Height Seated (Max) 0.071 1.80mm
Height 1.65mm
Technical
RMS Current (Irms) 320mA
Inductance Tolerance 30%
Current - Saturation 220mA
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 12MHz
Max DC Current 320mA
DC Resistance (DCR) 1.45Ohm Max
Test Frequency 100kHz
Inductance 68μH
Current Rating 320mA
Shielding Shielded
Current Rating (Amps) 320mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.150Lx0.150W 3.80mmx3.80mm
Series WE-TPC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Supplier Device Package 3816
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
