744031010
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TPC Nonstandard 0.150Lx0.150W 3.80mmx3.80mm 1muH
PDF
/
Buying Options
Total Price: USD $10.99
Unit Price: USD $10.9877
≥1 USD $10.9877
≥10 USD $9.0155
≥100 USD $8.73335
≥500 USD $8.45215
≥1000 USD $8.17
Inventory: 1162
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 3816
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-TPC
Size / Dimension 0.150Lx0.150W 3.80mmx3.80mm
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 2A
Shielding Shielded
Current Rating 2A
Inductance 1μH
Test Frequency 100kHz
DC Resistance (DCR) 37mOhm Max
Max DC Current 2A
Frequency - Self Resonant 144MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.6A
Inductance Tolerance 30%
RMS Current (Irms) 2A
Dimensions
Height 1.65mm
Height Seated (Max) 0.071 1.80mm
Length 3.8mm
Width 3.8mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
