744025150
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TPC Nonstandard 0.110Lx0.110W 2.80mmx2.80mm 15muH
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.65965
≥1 USD $1.65965
≥10 USD $1.36135
≥100 USD $1.31955
≥500 USD $1.2768
≥1000 USD $1.23405
Inventory: 1095
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Supplier Device Package 2828
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-TPC
Size / Dimension 0.110Lx0.110W 2.80mmx2.80mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 720mA
Shielding Shielded
Depth 2.8mm
Current Rating 720mA
Inductance 15μH
Test Frequency 100kHz
DC Resistance (DCR) 400mOhm Max
Max DC Current 720mA
Frequency - Self Resonant 32MHz
Inductance Frequency - Test 100kHz
Current - Saturation 900mA
Inductance Tolerance 20%
RMS Current (Irms) 720mA
Series Resistance 356mOhm
Dimensions
Height 2.8mm
Height Seated (Max) 0.118 3.00mm
Length 2.8mm
Width 2.794mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
