IHLP3232DZER220M51
RoHS
/
Package 3232
Category Inductors, Coils, Chokes / Fixed Inductors
Description
3232 22muH 20%
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.240024
≥1 USD $1.240024
≥10 USD $1.169823
≥100 USD $1.103612
≥500 USD $1.041146
≥1000 USD $0.982216
Inventory: 1123
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case 3232
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material COMPOSITE
Technical
Packaging Tape & Reel (TR)
Tolerance 20%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 155°C
Min Operating Temperature -55°C
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding Shielded
Number of Functions 1
Depth 8.26mm
Reach Compliance Code unknown
Current Rating 3.7A
Military Standard Not
Inductance 22 μH
Test Frequency 100kHz
Max DC Current 3.8A
Frequency - Self Resonant 9MHz
Inductor Application DC-DC CONVERTER
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 3.8A
DC Resistance (DCR) - Parallel 110.21mOhm
Inductance-Nom (L) 22 μH
Dimensions
Height 4mm
Height Seated (Max) 4.0132mm
Length 8.1788mm
Width 8.1788mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
