IR02SH221K
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Ind Molded 220uH 10% 790KHz 30Q-Factor Ferrite 52mA AXL T/R
PDF
/
Inventory: 2368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Axial
Material - Core Ferrite
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel
Series IR
Size / Dimension 0.120Diax0.260L 3.02mmx6.60mm
Tolerance ±10%
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR
Shielding Unshielded
Construction Epoxy Coated
Lead Length 36.515mm
Lead Diameter 0.508 mm
Inductance 220μH
DC Resistance (DCR) 21Ohm Max
Max DC Current 52mA
Frequency - Self Resonant 9MHz
Q @ Freq 30 @ 790kHz
Quality Factor-Min (at L-nom) 30
Inductance Frequency - Test 790kHz
Inductor Type GENERAL PURPOSE INDUCTOR
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
