IM04EV2R2K
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Molded Obsolete 8504.50.80.00 Fixed Inductor -55C~105C 135MHz 950mOhm Max 2.2muH
PDF
/
Inventory: 1933
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Inductance Frequency - Test 7.9MHz
Q @ Freq 33 @ 7.9MHz
Frequency - Self Resonant 135MHz
DC Resistance (DCR) 950mOhm Max
Inductance 2.2μH
Shielding Unshielded
Current Rating (Amps) 435mA
HTS Code 8504.50.80.00
Type Molded
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Tolerance ±10%
Size / Dimension 0.155Diax0.375L 3.94mmx9.53mm
Series IM
Operating Temperature -55°C~105°C
Physical
Material - Core Iron
Package / Case Axial
Mounting Type Through Hole
