IHSM3825PJ180L

Vishay Dale
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Active 2016 Bulk Fixed Inductor -55C~125C 1kHz 306mOhm Max 18muH
PDF
/
Inventory: 3464
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Width 6.35mm
Length 11.176mm
Height Seated (Max) 0.225 5.72mm
Height 5.715mm

Technical

Current - Saturation 1.05A
Inductance Frequency - Test 1kHz
Max DC Current 1.13A
DC Resistance (DCR) 306mOhm Max
Test Frequency 1kHz
Inductance 18μH
Current Rating 1.13A
Depth 6.35mm
Shielding Unshielded
Current Rating (Amps) 1.13A
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 0.440Lx0.250W 11.18mmx6.35mm
Series IHSM-3825
Published 2016
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
