IHLP2525CZER220M5A
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
IHLP-2525CZ-5A Nonstandard 0.270Lx0.255W 6.86mmx6.47mm 22muH
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $0.92488
≥100 USD $0.840576
≥500 USD $0.79024
≥1000 USD $0.655688
≥3000 USD $0.605264
Inventory: 1240
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 111 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2016
Series IHLP-2525CZ-5A
Size / Dimension 0.270Lx0.255W 6.86mmx6.47mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Molded
Max Operating Temperature 155°C
Min Operating Temperature -55°C
Current Rating (Amps) 2.8A
Shielding Shielded
Depth 6.72mm
Current Rating 2.8A
Military Standard Not
Inductance 22μH
Test Frequency 100kHz
DC Resistance (DCR) 174mOhm Max
Max DC Current 2.2A
Frequency - Self Resonant 8.3MHz
Inductance Frequency - Test 100kHz
Current - Saturation 2.2A
Inductance Tolerance 20%
Dimensions
Height 3mm
Height Seated (Max) 0.118 3.00mm
Length 6.86mm
Width 6.47mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings AEC-Q200
