TCK-071
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Common Mode Choke for use with TON 15-48xxWI Series
PDF
/
Buying Options
Total Price: USD $4.9
Unit Price: USD $4.896074
≥1 USD $4.896074
≥10 USD $4.618931
≥100 USD $4.357485
≥500 USD $4.110834
≥1000 USD $3.878144
Inventory: 1778
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Operating Temperature -40°C~125°C
Published 2008
Size / Dimension 0.307Lx0.276W 7.80mmx7.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Resistance 100mOhm
Current Rating (Amps) 1.8A
Shielding Unshielded
Inductance 18μH
DC Resistance (DCR) 100mOhm
Inductance Frequency - Test 1kHz
Dimensions
Height Seated (Max) 0.217 5.50mm
Compliance
RoHS Status ROHS3 Compliant
