5500R-183K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
5500R Nonstandard 1.050Lx0.495W 26.67mmx12.57mm 18muH
PDF
/
Inventory: 8816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.520 13.21mm
Height 12.96mm
Technical
Current - Saturation 4.15A
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 6.72A
DC Resistance (DCR) 22mOhm Max
Test Frequency 1kHz
Inductance 18μH
Current Rating 6.72A
Construction Rectangular
Depth 12.96mm
Number of Functions 1
Shielding NO
Packing Method TR, Paper, 13 Inch
HTS Code 8504.50.80.00
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 1.050Lx0.495W 26.67mmx12.57mm
Series 5500R
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~130°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 5 Weeks
