SC552R2KR
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SC55Sigma Inductors Axial 0.165Diax0.394L 4.20mmx10.00mm 2.2muH
PDF
/
Inventory: 4205
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 29 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series SC55, Sigma Inductors
Size / Dimension 0.165Diax0.394L 4.20mmx10.00mm
Tolerance ±10%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Construction Flame Retardant
Current Rating 1.8A
Military Standard Not
Lead Length 30mm
Lead Diameter 0.6 mm
Inductance 2.2μH
ELV Compliant
Test Frequency 7.9MHz
DC Resistance (DCR) 60mOhm Max
Max DC Current 1.8A
Frequency - Self Resonant 130MHz
Inductor Application RF INDUCTOR
Q @ Freq 60 @ 7.9MHz
Quality Factor-Min (at L-nom) 60
Inductor Type GENERAL PURPOSE INDUCTOR
DC Current 1.8A
Compliance
RoHS Status RoHS Compliant
