MGDH3-00005

TE Connectivity
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description RoHS Compliant Lead Free Tape & Reel (TR) Surface Mount Fixed Inductor 85C 100kHz 10mOhm 3.9muH
PDF
/
Inventory: 5621
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case Nonstandard

Technical

Packaging Tape & Reel (TR)
Tolerance 20%
Resistance 10mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Shielding Unshielded
Depth 16.26mm
Current Rating 9A
Inductance 3.9 μH
ELV Compliant
Test Frequency 100kHz
Max DC Current 9A
Current - Saturation 15A
DC Resistance (DCR) - Parallel 10mOhm

Dimensions

Height 8mm
Height Seated (Max) 8.001mm
Length 22.352mm
Width 16.256mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
