DT0703-2R2M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Contains Lead Tape & Reel (TR) Surface Mount Fixed Inductor 85C 100kHz 60mOhm 2.2muH
PDF
/
Inventory: 7519
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Technical
Packaging Tape & Reel (TR)
Tolerance 20%
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Shielding Shielded
Depth 4.5mm
Current Rating 1.5A
Inductance 2.2 μH
Test Frequency 100kHz
Max DC Current 1.5A
DC Resistance (DCR) - Parallel 60mOhm
Dimensions
Height 2.92mm
Height Seated (Max) 2.921mm
Length 6.604mm
Width 4.4958mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
