DQ1280-820M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Contains Lead WRAPAROUND fixed air core inductor 85C 100kHz 160mOhm 82muH
PDF
/
Inventory: 8763
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material AMORPHOUS MAGNETIC
Technical
Packaging Tape & Reel (TR)
Series DQ1280
Tolerance 20%
Pbfree Code no
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR
Shielding Shielded
Number of Functions 1
Current Rating 1.95A
Inductance 82 μH
Test Frequency 100kHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 1.95A
Case/Size Code 4949
DC Resistance (DCR) - Parallel 160mOhm
Inductance-Nom (L) 82 μH
Dimensions
Height Seated (Max) 8.001mm
Length 12.8016mm
Width 12.8016mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
