DN8155-820K

TE Connectivity
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Contains Lead Tape & Reel (TR) Surface Mount Fixed Inductor 85C 2.52MHz 370mOhm 82muH
PDF
/
Inventory: 4956
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Width 7.2898mm
Length 8.1026mm
Height Seated (Max) 5.5118mm

Technical

DC Resistance (DCR) - Parallel 370mOhm
Test Frequency 2.52MHz
Inductance 82 μH
Current Rating 780mA
Shielding Unshielded
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Tolerance 10%
Packaging Tape & Reel (TR)

Physical

Package / Case Nonstandard
Mount Surface Mount
