DN4835-180K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Contains Lead Tape & Reel (TR) Surface Mount fixed air core inductor 85C 2.52MHz 338mOhm 18muH
PDF
/
Inventory: 8819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Technical
Packaging Tape & Reel (TR)
Tolerance 10%
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Shielding Unshielded
Current Rating 840mA
Inductance 18 μH
Test Frequency 2.52MHz
Current - Saturation 840mA
DC Resistance (DCR) - Parallel 338mOhm
Dimensions
Height Seated (Max) 3.5052mm
Length 4.8006mm
Width 4.2926mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
