B82477R4105M100
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
EPCOS B82477R4105M100 Surface Mount Power Inductor, B82477R4 Series, 1 mH, 650 mA, 1.05 A, Shielded, 1.35 ohm
PDF
/
Buying Options
Total Price: USD $2.18
Unit Price: USD $2.1824
≥1 USD $2.1824
≥10 USD $1.85416
≥100 USD $1.70896
≥500 USD $1.527152
≥1000 USD $1.272656
Inventory: 447
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -55°C~150°C
Packaging Tape & Reel (TR)
Series B82477R4
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 720mA
Shielding Shielded
Inductance 1mH
DC Resistance (DCR) 1.35Ohm Max
Inductance Frequency - Test 100kHz
Current - Saturation 950mA
Dimensions
Height Seated (Max) 0.335 8.50mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
