B82468A4682M

TDK Electronics Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Obsolete WRAPAROUND fixed air core inductor -55C~125C 100kHz 240mOhm 6.8muH
PDF
/
Inventory: 6776
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series B82468A4
Size / Dimension 0.118Lx0.118W 3.00mmx3.00mm
Tolerance ±20%
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Terminal Finish TIN OVER NICKEL
HTS Code 8504.50.80.00
Current Rating (Amps) 880mA
Shielding NO
Number of Functions 1
Reach Compliance Code unknown
Inductance 6.8μH
Test Frequency 0.1MHz
DC Resistance (DCR) 240mOhm
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductance Frequency - Test 100kHz
Current - Saturation 1.1A
Rated Current-Max 0.88A

Dimensions

Height Seated (Max) 0.055 1.40mm

Compliance

RoHS Status ROHS3 Compliant
