B82432A1472K000
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Inductor GP Chip Molded Wirewound 4.7uH 10% 1MHz 30Q-Factor Ferrite 390mA 650mOhm DCR 1812 Blister T/R
PDF
/
Inventory: 9893
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.126 3.20mm
Technical
Inductance Frequency - Test 1MHz
Q @ Freq 30 @ 7.96MHz
Frequency - Self Resonant 110MHz
DC Resistance (DCR) 650mOhm Max
Inductance 4.7μH
Shielding Unshielded
Current Rating (Amps) 390mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±10%
Size / Dimension 0.177Lx0.126W 4.50mmx3.20mm
Series SIMID
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Ferrite
Supplier Device Package 1812 (4532 Metric)
Package / Case 2-SMD, J-Lead
Mounting Type Surface Mount
