B82144B1104J000
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RF Choke Wirewound 100uH 5% 100KHz 40Q-Factor Ferrite 760mA 700mOhm DCR RDL T/R
PDF
/
Inventory: 8846
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.571 14.50mm
Technical
Inductance Frequency - Test 100kHz
Q @ Freq 40 @ 796kHz
Frequency - Self Resonant 5.2MHz
DC Resistance (DCR) 700mOhm Max
Inductance 100μH
Shielding Unshielded
Current Rating (Amps) 760mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.256Dia 6.50mm
Series LBC
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Ferrite
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
