MLZ2012N101L
RoHS
/
Package 0805
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Lead Free WRAPAROUND Fixed Inductor 125C 12MHz 3.5Ohm 100μH
PDF
/
Inventory: 3915
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 0805
Surface Mount YES
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material FERRITE
Technical
Series MLZ2012
Tolerance 20%
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Construction Multilayer Chip
Current Rating 30mA
Operating Temperature (Max) 125°C
Operating Temperature (Min) -55°C
Test Frequency 2MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 3.5Ohm
Rated Current-Max 0.14A
Inductance-Nom (L) 100 μH
Special Feature DCR IS MEASURED AT 30% TOLERANCE
Self Resonant Frequency 12MHz
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
