MLF2012DR33M
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
MLF 0805 (2012Metric) 0.079Lx0.049W 2.00mmx1.25mm 330nH
PDF
/
Inventory: 5194
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2011
Series MLF
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±20%
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Multilayer
Terminal Finish Tin/Silver (Sn/Ag)
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding Shielded
Number of Functions 1
Current Rating 250mA
Case Code (Metric) 2012
Case Code (Imperial) 0805
Inductance 330nH
Test Frequency 25MHz
DC Resistance (DCR) 400mOhm Max
Current 15mA
Max DC Current 250mA
Frequency - Self Resonant 200MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 20 @ 25MHz
Quality Factor-Min (at L-nom) 20
Q Factor 30
Dimensions
Height 1.2446mm
Height Seated (Max) 0.041 1.05mm
Compliance
RoHS Status ROHS3 Compliant
