LBC2012T1R0M
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
LB C Type 0805 (2012Metric) 0.079Lx0.049W 2.00mmx1.25mm 1muH
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
≥10 USD $0.1188
≥100 USD $0.108768
≥500 USD $0.09592
≥1000 USD $0.083952
≥3000 USD $0.079974
Inventory: 1253
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Terminal Shape WRAPAROUND
Number of Pins 2
Shape/Size Description RECTANGULAR PACKAGE
Core Material Ferrite
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series LB, C Type
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Packing Method Tape, Embossed
Shielding Unshielded
Number of Functions 1
Depth 1.45mm
Construction Chip
Current Rating 620mA
Case Code (Metric) 2012
Case Code (Imperial) 0805
Inductance 1μH
Test Frequency 7.96MHz
DC Resistance (DCR) 190mOhm
Max DC Current 620mA
Frequency - Self Resonant 100MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Halogen Free Halogen Free
Inductance Tolerance 20%
Special Feature DCR IS MEASURED AT 30% TOLERANCE
Dimensions
Height 1.25mm
Height Seated (Max) 0.057 1.45mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
