CDH80D48NP-101KC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active Tape & Reel (TR) fixed air core inductor -40C~105C 100kHz 330mOhm Max 100muH
PDF
/
Buying Options
Total Price: USD $1.5
Unit Price: USD $1.496
≥1 USD $1.496
≥10 USD $1.27072
≥100 USD $1.171456
≥500 USD $1.046848
≥1000 USD $0.872344
≥3000 USD $0.847405
Inventory: 527
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series CDH80D48
Size / Dimension 0.331Lx0.315W 8.40mmx8.00mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 1.03A
Shielding Unshielded
Inductance 100μH
DC Resistance (DCR) 330mOhm Max
Inductance Frequency - Test 100kHz
Current - Saturation 1.02A
Dimensions
Height Seated (Max) 0.197 5.00mm
Compliance
RoHS Status ROHS3 Compliant
