SCR105B-820
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Obsolete 2009 Tape & Reel (TR) Fixed Inductor -40C~125C 2.52kHz 280mOhm Max 82muH
PDF
/
Inventory: 4831
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2009
Series SCR105B
Size / Dimension 0.413Lx0.374W 10.50mmx9.50mm
Tolerance ±20%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 1.57A
Shielding Shielded
Current Rating 790mA
Inductance 82μH
Test Frequency 2.52kHz
DC Resistance (DCR) 280mOhm Max
Inductance Frequency - Test 2.52kHz
Current - Saturation 790mA
Dimensions
Height 5.5118mm
Height Seated (Max) 0.217 5.50mm
Length 10.4902mm
Width 9.4996mm
Compliance
RoHS Status ROHS3 Compliant
