SC3340F-2R2

Signal Transformer
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active 2009 Fixed Inductor -40C~125C 100kHz 15mOhm Max 2.2muH
PDF
/
Inventory: 3860
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 9.906mm
Length 13.462mm
Height Seated (Max) 0.450 11.43mm
Height 11.43mm

Technical

Current - Saturation 14A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 15mOhm Max
Test Frequency 100kHz
Inductance 2.2μH
Current Rating 14A
Shielding Unshielded
Current Rating (Amps) 11.5A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.530Lx0.390W 13.45mmx9.90mm
Series SC3340F
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 18 Weeks

Alternative Model

P1171.222NLT

P1171.222NLT

Pulse Electronics Power

Recommended For You

SRP1045-2R2M
