SRP1045-2R2M image
Favorite
SRP1045-2R2M image
Favorite

SRP1045-2R2M

Bourns Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description SRP1045 Nonstandard 0.433Lx0.368W 11.00mmx9.35mm 2.2muH
PDF
/
Inventory: 1892
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~150°C
Packaging Tape & Reel (TR)
Published 2011
Series SRP1045
Size / Dimension 0.433Lx0.368W 11.00mmx9.35mm
Tolerance ±20%
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Copper/Nickel/Tin (Cu/Ni/Sn)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 9.65mm
Current Rating 9.5A
Inductance 2.2μH
Test Frequency 100kHz
DC Resistance (DCR) 8.7mOhm Max
Max DC Current 9.5A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Current - Saturation 10A
Case/Size Code 4237

Dimensions

Height 4.5mm
Height Seated (Max) 0.189 4.80mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
