PL9104NL
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Active Tube Surface Mount Fixed Inductor -55C~130C 11mOhm Max 3.9muH ±30%
PDF
/
Inventory: 1422
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.248 6.30mm
Technical
Current - Saturation 7.2A
DC Resistance (DCR) 11mOhm Max
Inductance 3.9μH
Shielding Shielded
Current Rating (Amps) 6.7A
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.413Lx0.413W 10.50mmx10.50mm
Series PL91XX
Packaging Tube
Operating Temperature -55°C~130°C
Physical
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
