PF0464.183NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PF0464NL Nonstandard 0.283Lx0.283W 7.20mmx7.20mm 18muH
PDF
/
Inventory: 2245
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series PF0464NL
Size / Dimension 0.283Lx0.283W 7.20mmx7.20mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding Shielded
Number of Functions 1
Depth 7.2mm
Current Rating 1.32A
Military Standard Not
Inductance 18μH
Test Frequency 100kHz
DC Resistance (DCR) 90mOhm Max
Max DC Current 1.32A
Frequency - Self Resonant 22MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
DC Current 1.32A
Dimensions
Height 2.9972mm
Height Seated (Max) 0.118 3.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
