PA4309.103NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PA4309.XXXNL Nonstandard 0.504Lx0.504W 12.80mmx12.80mm 10muH
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $0.924
≥100 USD $0.839872
≥500 USD $0.789536
≥1000 USD $0.65516
≥3000 USD $0.604736
Inventory: 3257
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series PA4309.XXXNL
Size / Dimension 0.504Lx0.504W 12.80mmx12.80mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding Unshielded
Current Rating 11A
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 52mOhm Max
Inductance Frequency - Test 100kHz
Dimensions
Height Seated (Max) 0.276 7.00mm
Compliance
RoHS Status RoHS Compliant
