PA2050.193NL
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PA2050NL Nonstandard 0.878Lx0.750W 22.30mmx19.05mm 19.4muH
PDF
/
Buying Options
Total Price: USD $4.06
Unit Price: USD $4.0568
≥1 USD $4.0568
≥10 USD $3.39152
≥100 USD $3.096544
≥500 USD $2.65408
≥1000 USD $2.432945
≥3000 USD $2.359218
Inventory: 661
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~130°C
Packaging Bulk
Series PA2050NL
Size / Dimension 0.878Lx0.750W 22.30mmx19.05mm
Tolerance ±10%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Resistance 12.6mOhm
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Depth 19.05mm
Military Standard Not
Inductance 19.4μH
DC Resistance (DCR) 12.6mOhm
Max DC Current 8.5A
Inductor Application POWER INDUCTOR
Current - Saturation 22A
Case/Size Code 8875
DC Current 8.5A
Dimensions
Height 12.2mm
Height Seated (Max) 0.480 12.20mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
