P1173.683NLT image
Favorite
P1173.683NLT image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description P1173NL Nonstandard 0.482Lx0.482W 12.24mmx12.24mm 68muH
PDF
/
Inventory: 9614
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Shape/Size Description RECTANGULAR PACKAGE
Core Material AMORPHOUS MAGNETIC
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Technical

Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Series P1173NL
Size / Dimension 0.482Lx0.482W 12.24mmx12.24mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Depth 12.24mm
Construction Chip
Current Rating 2.1A
Military Standard Not
Inductance 68μH
Test Frequency 100kHz
DC Resistance (DCR) 135mOhm Max
Max DC Current 2.1A
Frequency - Self Resonant 6MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
DC Current 2.1A
Case/Size Code 4848

Supply Chain

Factory Lead Time 11 Weeks

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.315 8.00mm
Height 8mm
