P1167.184NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
P1167NL Nonstandard 0.297Lx0.297W 7.54mmx7.54mm 180muH
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.032549
≥1 USD $1.032549
≥10 USD $0.974108
≥100 USD $0.918963
≥500 USD $0.866944
≥1000 USD $0.817874
Inventory: 1121
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material AMORPHOUS MAGNETIC
Technical
Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Series P1167NL
Size / Dimension 0.297Lx0.297W 7.54mmx7.54mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Resistance 820mOhm
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Depth 7.54mm
Construction Chip
Current Rating 470mA
Military Standard Not
Inductance 180μH
Test Frequency 100kHz
DC Resistance (DCR) 820mOhm Max
Max DC Current 470mA
Frequency - Self Resonant 4.5MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 3030
DC Current 470mA
Dimensions
Height 4.5mm
Height Seated (Max) 0.177 4.50mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
