P0648.653NLT
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Fixed Inductors UNSHIELDED DRUM CORE
PDF
/
Inventory: 3934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.197 5.00mm
Height 5mm
Technical
Case/Size Code 5151
Current - Saturation 2A
Max DC Current 1.8A
DC Resistance (DCR) 166mOhm Max
Test Frequency 100kHz
Inductance 65μH
Current Rating 1.8A
Depth 13.08mm
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.515Lx0.515W 13.08mmx13.08mm
Series P0648
Packaging Tape & Reel (TR)
Operating Temperature -40°C~130°C
Physical
Core Material Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
