ELL-VEG680M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
G Nonstandard 0.118Lx0.118W 3.00mmx3.00mm 68muH
PDF
/
Inventory: 5687
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Technical
Packaging Tape & Reel (TR)
Series G
Size / Dimension 0.118Lx0.118W 3.00mmx3.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Depth 3.2mm
Current Rating 220mA
Inductance 68μH
Test Frequency 100kHz
DC Resistance (DCR) 3.5Ohm
Max DC Current 220mA
Inductor Application DC-DC CONVERTER
Terminal Placement DUAL ENDED
Current - Saturation 180mA
Case/Size Code 1212
Series Resistance 3.5Ohm
Special Feature DCR IS MEASURED AT 20% TOLERANCE
Dimensions
Height 1mm
Height Seated (Max) 0.039 1.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
