ELC-3GN4R7N
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
N Nonstandard 0.126Lx0.126W 3.20mmx3.20mm 4.7muH
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.673052
≥1 USD $0.673052
≥10 USD $0.634955
≥100 USD $0.599006
≥500 USD $0.565102
≥1000 USD $0.533109
Inventory: 1133
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Packaging Tape & Reel (TR)
Published 2005
Series N
Size / Dimension 0.126Lx0.126W 3.20mmx3.20mm
Tolerance ±30%
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Depth 3.5mm
Current Rating 760mA
Case Code (Metric) 3225
Case Code (Imperial) 1210
Inductance 4.7μH
Test Frequency 100kHz
DC Resistance (DCR) 200mOhm
Current 5.6A
Max DC Current 760mA
Case/Size Code 1212
Dimensions
Height 1.5494mm
Height Seated (Max) 0.059 1.50mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
