ELC-18E560L image
Favorite
ELC-18E560L image
Favorite
RoHS
RoHS RoHS compliant
Package Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description 18E-L Radial Vertical Cylinder 0.748Dia 19.00mm 56muH
PDF
/
Inventory: 6235
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Material - Core Ferrite

Technical

Packaging Bulk
Series 18E-L
Size / Dimension 0.748Dia 19.00mm
Tolerance ±10%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 3.8A
Shielding Shielded
Current Rating 3.8A
Lead Pitch 11.3mm
Inductance 56μH
Test Frequency 10kHz
DC Resistance (DCR) 31mOhm
Current 390mA
Max DC Current 3.8A
Lead/Base Style Radial
Inductance Frequency - Test 10kHz
Inductance Tolerance 10%
RMS Current (Irms) 3.8A

Dimensions

Height 25.0952mm
Height Seated (Max) 0.988 25.10mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
