ELC-15E150
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
15E Radial Vertical Cylinder 0.630Dia 16.00mm 15muH
PDF
/
Inventory: 913
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Surface Mount NO
Shape/Size Description CYLINDRICAL PACKAGE
Core Material FERRITE
Technical
Packaging Bulk
Published 2002
Series 15E
Size / Dimension 0.630Dia 16.00mm
Tolerance ±20%
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin/Copper (Sn/Cu)
HTS Code 8504.50.80.00
Current Rating (Amps) 4.7A
Shielding YES
Number of Functions 1
Construction Cylindrical
Reach Compliance Code compliant
Operating Temperature (Max) 105°C
Operating Temperature (Min) -20°C
Lead Length 4.5mm
Lead Diameter 0.7 mm
Inductance 15μH
Test Frequency 0.01MHz
DC Resistance (DCR) 22mOhm
Inductor Application POWER INDUCTOR
Inductance Frequency - Test 10kHz
Rated Current-Max 4.7A
Special Feature DC RESISTANCE IS MEASURED AT 20% TOLERANCE
Dimensions
Height Seated (Max) 0.906 23.00mm
Compliance
RoHS Status RoHS Compliant
