ELC-12E150L
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
12E Radial Vertical Cylinder 0.531Dia 13.50mm 15muH
PDF
/
Inventory: 962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Shape/Size Description CYLINDRICAL PACKAGE
Core Material Ferrite
Technical
Packaging Bulk
Series 12E
Size / Dimension 0.531Dia 13.50mm
Tolerance ±20%
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin/Copper (Sn/Cu)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Construction Cylindrical
Current Rating 3.2A
Lead Pitch 7mm
Operating Temperature (Max) 105°C
Operating Temperature (Min) -20°C
Lead Length 3.5mm
Inductance 15μH
Test Frequency 10kHz
DC Resistance (DCR) 28mOhm
Current 2A
Max DC Current 3.2A
Inductor Application POWER INDUCTOR
Lead/Base Style Radial
Inductance Tolerance 20%
RMS Current (Irms) 3.2A
Dimensions
Height 18.4912mm
Height Seated (Max) 0.768 19.50mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
