481R0SC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard, 4 Lead
Category Inductors, Coils, Chokes / Fixed Inductors
Description
4800S Nonstandard 4Lead 0.480Lx0.480W 12.20mmx12.20mm 1muH
PDF
/
Buying Options
Total Price: USD $6.46
Unit Price: USD $6.46285
≥1 USD $6.46285
≥10 USD $5.3029
≥100 USD $5.1376
≥500 USD $4.97135
≥1000 USD $4.80605
Inventory: 1166
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard, 4 Lead
Terminal Shape ONE SURFACE
Number of Pins 2
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 4800S
Size / Dimension 0.480Lx0.480W 12.20mmx12.20mm
Tolerance ±30%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Depth 12.5mm
Current Rating 10A
Inductance 1μH
Test Frequency 1MHz
DC Resistance (DCR) 6mOhm Max
Max DC Current 10A
Frequency - Self Resonant 83MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 35 @ 1MHz
Inductance Frequency - Test 10kHz
Q Factor 35
Inductance Tolerance 30%
RMS Current (Irms) 10A
Dimensions
Height 6mm
Height Seated (Max) 0.236 6.00mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
