23S4R7C
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
2300 Nonstandard 0.244Lx0.220W 6.20mmx5.60mm 4.7muH
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.63124
≥1 USD $0.63124
≥10 USD $0.59551
≥100 USD $0.5618
≥500 USD $0.53
≥1000 USD $0.5
≥3000 USD $0.4717
Inventory: 9347
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Number of Pins 2
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 2300
Size / Dimension 0.244Lx0.220W 6.20mmx5.60mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Depth 5.6mm
Current Rating 1.6A
Military Standard Not
Lead Pitch 1.7mm
Inductance 4.7μH
Test Frequency 1kHz
DC Resistance (DCR) 44mOhm Max
Max DC Current 1.6A
Terminal Placement DUAL ENDED
DC Current 1.6A
Dimensions
Height 3.2mm
Height Seated (Max) 0.126 3.20mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
