1433428C
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
1400 Radial Vertical Cylinder 1.020Dia 25.91mm 330muH
PDF
/
Buying Options
Total Price: USD $2.03
Unit Price: USD $2.02959
≥1 USD $2.02959
≥10 USD $1.914708
≥100 USD $1.806329
≥500 USD $1.704081
≥1000 USD $1.607618
Inventory: 922
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Seated (Max) 0.610 15.50mm
Height 1.5mm
Technical
Saturation Current 2.8A
Special Feature Q MEASURED AT 0.05 MHZ
RMS Current (Irms) 2.8A
DC Current 2.8A
Inductance Tolerance 10%
Q Factor 22
Inductance Frequency - Test 1kHz
Quality Factor-Min (at L-nom) 22
Lead/Base Style Radial
Q @ Freq 22 @ 50kHz
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 2.5MHz
Max DC Current 2.8A
DC Resistance (DCR) 150mOhm Max
Test Frequency 50kHz
Inductance 330μH
Lead Diameter 0.76 mm
Lead Length 10mm
Lead Pitch 23.4mm
Military Standard Not
Current Rating 2.8A
Construction Bobbin Type
Depth 24.4mm
Number of Functions 1
Shielding NO
Orientation Vertical
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 1.020Dia 25.91mm
Series 1400
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Shape/Size Description CYLINDRICAL PACKAGE
Number of Pins 2
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Mount Radial, Through Hole
Supply Chain
Factory Lead Time 8 Weeks
