MBH7045C-680MA=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
MBH7045C Nonstandard 0.283Lx0.283W 7.20mmx7.20mm 68muH
PDF
/
Inventory: 2621
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Tape & Reel (TR)
Series MBH7045C
Size / Dimension 0.283Lx0.283W 7.20mmx7.20mm
Tolerance ±20%
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Current Rating 1.1A
Operating Temperature (Max) 150°C
Operating Temperature (Min) -40°C
Inductance 68μH
Test Frequency 100kHz
DC Resistance (DCR) 210mOhm Max
Terminal Placement DUAL ENDED
Inductance Frequency - Test 100kHz
Current - Saturation 780mA
Dimensions
Height Seated (Max) 0.189 4.80mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
