LQP03TN33NJ04D
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description
33nH 5% 5%
PDF
/
Inventory: 1123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status DISCONTINUED (Last Updated: 4 weeks ago)
Physical
Mount Surface Mount
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Tape & Reel
Tolerance 5%
JESD-609 Code e4
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Resistance 2.95Ohm
Terminal Finish Gold (Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Packing Method TR, Paper, 7 Inch
Shielding Unshielded
Number of Functions 1
Depth 350μm
Construction Chip
Current Rating 60mA
Military Standard Not
Case Code (Metric) 0603
Case Code (Imperial) 0201
Inductance 33 nH
Test Frequency 300MHz
Max DC Current 60mA
Frequency - Self Resonant 2GHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 8
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 8
DC Resistance (DCR) - Parallel 2.95Ohm
Inductance Tolerance 5%
Inductance-Nom (L) 0.033 μH
DC Current 60mA
Dimensions
Height 304.8μm
Length 609.6μm
Width 304.8μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
