0805CS-330XGLB
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Active Contains Lead Fixed Inductor 125C 2.15GHz 270mOhm 33nH
PDF
/
Buying Options
Total Price: USD $4.86
Unit Price: USD $4.8602
≥1 USD $4.8602
≥10 USD $3.9881
≥100 USD $3.86365
≥500 USD $3.73825
≥1000 USD $3.6138
Inventory: 20303
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 18 hours ago)
Physical
Surface Mount YES
Terminal Shape WRAPAROUND
Weight 5.499807mg
Material - Core Ceramic
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Cut Tape
Published 2009
Tolerance 2%
Pbfree Code yes
Part Status Active
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Silver/Palladium/Platinum - with Glass frit
Max Operating Temperature 125°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Construction Rectangular
Current Rating 500mA
Reference Standard AEC-Q200
Case Code (Metric) 2012
Case Code (Imperial) 0805
Inductance 33 nH
Test Frequency 250MHz
Max DC Current 500mA
Frequency - Self Resonant 2.15GHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 60
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 60
DC Resistance (DCR) - Parallel 270mOhm
Inductance Tolerance 2%
Inductance-Nom (L) 0.033 μH
Special Feature Q IS MEASURED AT 500 MHZ
Dimensions
Height 1.52mm
Length 2.29mm
Width 1.73mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Contains Lead
