LQP02TN1N4S02D
RoHS
/
Package 600
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 125C 6GHz 600mOhm 1.4nH
PDF
/
Inventory: 9017
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Construction Rectangular
Current Rating 220mA
Case Code (Metric) 0402
Case Code (Imperial) 1005
Inductance 1.4 nH
Test Frequency 500MHz
Frequency - Self Resonant 6GHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 8
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 0201
DC Resistance (DCR) - Parallel 600mOhm
Rated Current-Max 0.22A
Inductance-Nom (L) 0.0014 μH
Number of Functions 1
Shielding Unshielded
Packing Method TR, 7 Inch
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 2
Tolerance 21.4286%
Packaging Tape & Reel (TR)
Dimensions
Height Seated (Max) 228.6μm
Length 406.4μm
Width 203.2μm
Compliance
RoHS Status RoHS Compliant
Physical
Core Material Film
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case 600
Mount Surface Mount
Alternative Model
