LQH32MN330K23L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
LQH32 Nonstandard 0.126Lx0.098W 3.20mmx2.50mm 33muH
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
≥10000 USD $1.7898
Inventory: 6004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.087 2.20mm
Height 1.5494mm
Technical
DC Current 115mA
Q Factor 40
Quality Factor-Min (at L-nom) 40
Q @ Freq 40 @ 1MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Max DC Current 115mA
Current 300mA
DC Resistance (DCR) 3.5Ohm Max
Test Frequency 1MHz
Inductance 33μH
Case Code (Imperial) 1210
Case Code (Metric) 3225
Military Standard Not
Frequency 12MHz
Current Rating 115mA
Depth 2.7mm
Number of Functions 1
Shielding NO
Packing Method TR, Embossed Plastic, 7 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn/Cu)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±10%
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series LQH32
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 59.987591mg
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
